Features:

Remote control unit for power output ON-OFF and power save mode, reset, error message, etc. by RS485 Switch selectable 50 or 60Hz output, all models Tightly regulated output voltage and frequency Thermostatically controlled cooling fan,Built-in battery voltage and output watts scale meter,Below 1-Watt consumption in power save mode, Microprocessor based design with absolutely accurate and stable frequency,Very low harmonic distortion, THD <3% Panel indicators for battery voltage & load level (%), Compact and lightweight, yet rugged and vehicle rated, 83-86% efficient, Capable of driving highly reactive loads such as electric tools and appliances, Built-in fast acting AC synchronized transfer switch (<10msec), The high frequency switching technology is applied for the lightweight design.

Product range 12V/24V-600watt~6000watt



Model Numbers:

DAI-0600U-12/DAI-0600U-24/DAI-0600U-48/DAI-1000U-12/DAI-1000U-24/DAI-1000U-48/DAI-1500U-12

DAI-1500U-24/DAI-1500U-48/DAI-3000U-12/DAI-3000U-24/DAI-3000U-48





Options:

Two 1-meter cables for the battery bank/Remote controller with 3-meter cable/Remote
controller with 15-meter cable



Others:

Output
power ranges are 600W ~ 3000W for 12V, 24V, 48V battery bank.

Uninterruptible
Power Supply (UPS) solution and need an external battery bank
